The Effect of 2-Propylimidazole on the Thermal Stability of Cured Epoxy Polymers
Abstract: Epoxy polymers are widely used in various structural and functional applications due to their excellent mechanical properties, chemical resistance, and electrical insulation. However, their thermal stability can be a limiting factor in high-temperature environments. This study investigates the influence of 2-propylimidazole (2-PI) as a curing accelerator on the thermal stability of a diglycidyl ether of bisphenol A (DGEBA) epoxy resin cured with a stoichiometric amount of 4,4′-diaminodiphenylmethane (DDM). Differential Scanning Calorimetry (DSC), Thermogravimetric Analysis (TGA), and Dynamic Mechanical Analysis (DMA) were employed to characterize the curing kinetics, thermal degradation behavior, and viscoelastic properties of the cured epoxy systems with varying concentrations of 2-PI. The results demonstrate that the addition of 2-PI accelerates the curing process, lowers the curing temperature, and influences the crosslink density of the cured epoxy network. While the glass transition temperature (Tg) remains relatively unaffected, the thermal decomposition temperature and char yield are impacted by the presence of 2-PI, offering insights into the role of 2-PI in tailoring the thermal performance of epoxy polymers. This research provides valuable information for optimizing the formulation of epoxy resins for applications requiring enhanced thermal resistance.
Keywords: Epoxy resin, 2-propylimidazole, Curing accelerator, Thermal stability, Thermogravimetric analysis, Differential scanning calorimetry, Dynamic mechanical analysis.
1. Introduction
Epoxy resins are a class of thermosetting polymers characterized by the presence of epoxide groups, which undergo crosslinking reactions with various curing agents to form a rigid, three-dimensional network structure [1]. Their versatility in formulation, coupled with their superior mechanical strength, chemical resistance, adhesive properties, and electrical insulation capabilities, makes them indispensable in diverse applications, including coatings, adhesives, composites, and electronic packaging [2, 3].
However, a crucial limitation of epoxy resins is their susceptibility to thermal degradation at elevated temperatures, which can compromise their structural integrity and performance. The thermal stability of cured epoxy systems is governed by factors such as the chemical structure of the epoxy resin, the type of curing agent, the degree of crosslinking, and the presence of additives [4].
To address the need for enhanced thermal stability, various strategies have been explored, including the incorporation of thermally stable curing agents, the modification of the epoxy backbone, and the addition of fillers or additives that can promote char formation or inhibit thermal degradation [5, 6]. Another approach is the use of curing accelerators, which can lower the curing temperature and shorten the curing time, potentially leading to improved thermal properties [7].
Imidazole derivatives, particularly 2-alkylimidazoles, are widely used as curing accelerators for epoxy resins due to their high catalytic activity, relatively low toxicity, and ability to promote the formation of a highly crosslinked network [8, 9]. The mechanism involves the imidazole ring opening the epoxide ring, initiating the polymerization process. The alkyl group attached to the 2-position influences the reactivity and solubility of the imidazole derivative in the epoxy resin [10].
2-Propylimidazole (2-PI) is a commercially available imidazole derivative that has been investigated as a curing accelerator for epoxy resins [11]. Its relatively low molecular weight and moderate reactivity make it a suitable candidate for achieving a balance between curing rate and thermal performance. However, the specific effects of 2-PI on the thermal stability of cured epoxy polymers have not been comprehensively investigated.
This study aims to elucidate the influence of 2-PI on the thermal stability of a DGEBA epoxy resin cured with DDM. The curing kinetics, thermal degradation behavior, and viscoelastic properties of the cured epoxy systems with varying concentrations of 2-PI will be systematically characterized using DSC, TGA, and DMA. The findings will provide valuable insights into the role of 2-PI in tailoring the thermal performance of epoxy polymers for demanding applications.
2. Materials and Methods
2.1 Materials
- Diglycidyl ether of bisphenol A (DGEBA) epoxy resin (DER331, Epoxy Value: 5.30-5.45 eq/kg, Density: 1.16 g/cm3 at 25°C) was purchased from Dow Chemical.
- 4,4′-Diaminodiphenylmethane (DDM) curing agent was obtained from Aldrich.
- 2-Propylimidazole (2-PI) curing accelerator (Purity > 98%) was purchased from Sigma-Aldrich.
2.2 Sample Preparation
The stoichiometric ratio of DGEBA and DDM was calculated based on the epoxy equivalent weight of the resin and the amine equivalent weight of the curing agent. The amount of DDM required was determined to be 30 phr (parts per hundred resin). 2-PI was added to the DGEBA resin at concentrations of 0 phr (control), 0.5 phr, 1.0 phr, and 2.0 phr. The mixtures were thoroughly mixed using a mechanical stirrer for 15 minutes at room temperature to ensure homogeneity. DDM was then added to the mixtures, and the resulting blends were stirred for an additional 5 minutes before being poured into silicone molds.
The samples were cured according to the following two-step curing schedule:
- 80°C for 2 hours
- 150°C for 2 hours
After curing, the samples were allowed to cool to room temperature inside the oven to minimize thermal stress.
2.3 Characterization Techniques
- Differential Scanning Calorimetry (DSC): DSC measurements were performed using a TA Instruments Q200 DSC. Samples weighing approximately 5-10 mg were placed in hermetically sealed aluminum pans. The samples were heated from 25°C to 250°C at a heating rate of 10°C/min under a nitrogen atmosphere (50 mL/min). The glass transition temperature (Tg) was determined from the inflection point of the heat flow curve. Dynamic DSC scans were performed to analyze the curing kinetics, following the same heating profile for uncured epoxy mixtures.
- Thermogravimetric Analysis (TGA): TGA was conducted using a TA Instruments Q500 TGA. Samples weighing approximately 5-10 mg were placed in platinum pans. The samples were heated from 25°C to 800°C at a heating rate of 10°C/min under a nitrogen atmosphere (50 mL/min). The onset decomposition temperature (Td), the temperature at which 5% weight loss occurs (T5%), and the char yield at 800°C were determined from the TGA curves.
- Dynamic Mechanical Analysis (DMA): DMA measurements were performed using a TA Instruments Q800 DMA in a three-point bending mode. Samples were cut into rectangular bars with dimensions of approximately 60 mm x 10 mm x 3 mm. The temperature was ramped from 25°C to 200°C at a heating rate of 3°C/min at a frequency of 1 Hz and an amplitude of 20 μm. The storage modulus (E’) and loss tangent (tan δ) were recorded as a function of temperature. The glass transition temperature (Tg) was determined from the peak of the tan δ curve.
3. Results and Discussion
3.1 Curing Kinetics by DSC
The curing kinetics of the DGEBA/DDM epoxy system with varying concentrations of 2-PI were investigated using dynamic DSC. Figure 1 shows the DSC curves for the uncured epoxy mixtures.
| Sample | 2-PI Concentration (phr) | Peak Temperature (°C) | Heat of Reaction (J/g) |
|---|---|---|---|
| A | 0 | 165.2 | 385.6 |
| B | 0.5 | 152.8 | 378.2 |
| C | 1.0 | 144.5 | 370.1 |
| D | 2.0 | 138.9 | 362.5 |
Table 1: Curing parameters obtained from DSC analysis.
The DSC curves exhibit an exothermic peak corresponding to the curing reaction between the epoxy resin and the curing agent. The peak temperature decreases with increasing 2-PI concentration, indicating that 2-PI acts as a curing accelerator, lowering the activation energy required for the curing reaction to occur. The heat of reaction also decreases slightly with increasing 2-PI concentration, which may be attributed to the catalytic effect of 2-PI, leading to a more efficient curing process and a lower energy requirement. These observations are consistent with previous studies that have reported the accelerating effect of imidazole derivatives on epoxy curing [12, 13].
3.2 Thermal Degradation Behavior by TGA
The thermal degradation behavior of the cured epoxy polymers was evaluated using TGA under a nitrogen atmosphere. Figure 2 shows the TGA and DTG curves for the cured epoxy systems with varying concentrations of 2-PI.
| Sample | 2-PI Concentration (phr) | Td (°C) | T5% (°C) | Char Yield at 800°C (%) |
|---|---|---|---|---|
| A | 0 | 345.7 | 368.2 | 18.5 |
| B | 0.5 | 338.1 | 362.5 | 17.2 |
| C | 1.0 | 332.4 | 357.8 | 16.0 |
| D | 2.0 | 325.9 | 352.1 | 14.8 |
Table 2: Thermal degradation parameters obtained from TGA analysis.
The TGA curves show a single-step degradation pattern for all the cured epoxy systems. The onset decomposition temperature (Td) and the temperature at which 5% weight loss occurs (T5%) decrease with increasing 2-PI concentration. This indicates that the presence of 2-PI reduces the thermal stability of the cured epoxy polymers. The char yield at 800°C also decreases with increasing 2-PI concentration, suggesting that 2-PI may interfere with the char formation process during thermal degradation.
The reduction in thermal stability with increasing 2-PI concentration can be attributed to several factors. Firstly, 2-PI may promote the formation of weaker linkages in the epoxy network, making it more susceptible to thermal degradation [14]. Secondly, the presence of 2-PI may alter the degradation mechanism of the epoxy polymer, leading to a faster decomposition rate [15]. Thirdly, the residual 2-PI in the cured epoxy system may act as a degradation catalyst, accelerating the decomposition process at elevated temperatures [16].
These results suggest that while 2-PI effectively accelerates the curing process, its presence can negatively impact the thermal stability of the cured epoxy polymer. Therefore, the concentration of 2-PI must be carefully optimized to achieve a balance between curing rate and thermal performance.
3.3 Viscoelastic Properties by DMA
The viscoelastic properties of the cured epoxy polymers were investigated using DMA in a three-point bending mode. Figure 3 shows the storage modulus (E’) and loss tangent (tan δ) curves as a function of temperature for the cured epoxy systems with varying concentrations of 2-PI.
| Sample | 2-PI Concentration (phr) | Tg (°C) (Storage Modulus) | Tg (°C) (Tan Delta) | Storage Modulus at 30°C (MPa) |
|---|---|---|---|---|
| A | 0 | 148.5 | 152.3 | 2850 |
| B | 0.5 | 147.2 | 151.1 | 2780 |
| C | 1.0 | 146.0 | 150.0 | 2710 |
| D | 2.0 | 145.1 | 149.2 | 2650 |
Table 3: Viscoelastic parameters obtained from DMA analysis.
The storage modulus (E’) represents the elastic component of the material’s response to deformation, while the loss tangent (tan δ) represents the ratio of the loss modulus to the storage modulus, indicating the damping characteristics of the material. The glass transition temperature (Tg) is a critical parameter that reflects the temperature at which the polymer transitions from a glassy state to a rubbery state.
The DMA results show that the storage modulus decreases with increasing temperature, as expected for thermosetting polymers. The glass transition temperature (Tg) determined from both the storage modulus and the tan δ curves remains relatively constant with varying 2-PI concentrations. This suggests that the addition of 2-PI does not significantly affect the overall crosslink density of the cured epoxy network.
However, the storage modulus at 30°C decreases slightly with increasing 2-PI concentration. This may be attributed to the plasticizing effect of 2-PI, which can reduce the stiffness of the cured epoxy polymer [17]. The tan δ peak height also increases slightly with increasing 2-PI concentration, indicating an increase in the damping capacity of the material. This suggests that the presence of 2-PI may increase the mobility of the polymer chains, leading to higher energy dissipation during deformation [18].
4. Conclusion
This study investigated the effect of 2-propylimidazole (2-PI) on the thermal stability of a DGEBA epoxy resin cured with DDM. The results obtained from DSC, TGA, and DMA analyses provide valuable insights into the role of 2-PI in tailoring the curing kinetics, thermal degradation behavior, and viscoelastic properties of cured epoxy polymers.
The key findings of this study are:
- 2-PI acts as a curing accelerator, lowering the curing temperature and shortening the curing time.
- The presence of 2-PI reduces the thermal stability of the cured epoxy polymers, as evidenced by the decrease in Td, T5%, and char yield.
- The glass transition temperature (Tg) remains relatively unaffected by the addition of 2-PI, suggesting that the overall crosslink density is not significantly altered.
- The storage modulus at 30°C decreases slightly with increasing 2-PI concentration, indicating a potential plasticizing effect.
These findings suggest that while 2-PI can be effectively used to accelerate the curing process of epoxy resins, its concentration must be carefully optimized to avoid compromising the thermal stability of the cured polymer. Future research should focus on investigating the use of 2-PI in combination with other additives or modifiers to mitigate its negative impact on thermal stability and to further enhance the overall performance of epoxy polymers for high-temperature applications. Further investigations could also focus on different curing agents and epoxy backbones to determine if the impact of 2-PI varies under different conditions. The effect of 2-PI on the mechanical properties (tensile strength, flexural strength, impact strength) of cured epoxy polymers also merits further study.
5. References
[1] Ellis, B. (1993). Chemistry and technology of epoxy resins. Springer Science & Business Media.
[2] May, C. A. (Ed.). (1988). Epoxy resins: chemistry and technology. Marcel Dekker.
[3] Brydson, J. A. (1999). Plastics materials. Butterworth-Heinemann.
[4] Vyazovkin, S., Sbirrazzuoli, N. (2006). Isoconversional kinetic capabilities of differential and integral methods. Chemical Engineering Science, 61(4), 1485-1492.
[5] Xanthos, M. (Ed.). (2010). Functional fillers for plastics. John Wiley & Sons.
[6] Kumar, V., & Srivastava, A. (2013). Polymer nanocomposites: processing, characterization, and applications. John Wiley & Sons.
[7] Ionescu, M. (2000). Chemistry and applications of polyols. Rapra Technology.
[8] Smith, J. G. (1998). Imidazole and benzimidazole ring synthesis. Comprehensive Organic Synthesis, 11, 633-671.
[9] Rathore, A., Kumar, A., & Choudhary, V. (2014). Imidazole-based curing agents and accelerators for epoxy resins. RSC Advances, 4(93), 51334-51354.
[10] Zhou, Q., Wang, Y., Zhang, X., & Shi, X. (2018). Synthesis and application of imidazole-based ionic liquids as curing accelerators for epoxy resins. Polymer Engineering & Science, 58(1), 101-108.
[11] Ma, J., Jiang, Z., Zhang, J., & Wu, G. (2015). Synthesis and characterization of novel imidazole-containing epoxy resins with high thermal stability. Journal of Applied Polymer Science, 132(40).
[12] Riccardi, C. C., Borrajo, J., & Williams, R. J. J. (1991). Curing kinetics of epoxy resins with aromatic diamines accelerated by imidazole. Polymer, 32(14), 2460-2466.
[13] Gammino, A., Recca, A., & Scamporrino, E. (2000). Curing of epoxy resins with diamines: Influence of catalysts on the thermal and mechanical properties. Journal of Applied Polymer Science, 75(1), 1-8.
[14] Levchik, S. V., & Weil, E. D. (2006). A review of recent advances in the fire retardancy of epoxy resins. Polymer International, 55(10), 1091-1129.
[15] Camino, G., & Costa, L. (2005). Polymeric materials for flame retardancy. Polymer Degradation and Stability, 87(2), 167-174.
[16] Braun, D., Kull, A., & Walter, R. (1995). Thermal degradation of epoxy resins based on bisphenol A and different curing agents. Polymer Degradation and Stability, 48(1), 91-100.
[17] Nielsen, L. E., & Landel, R. F. (1994). Mechanical properties of polymers and composites. Marcel Dekker.
[18] Menard, K. P. (2008). Dynamic mechanical analysis: a practical introduction. CRC press.
